Features :
- Single Piece Moulded Without Any Joints
- Concealed Metal Higes
- Mounting Screws Fitted From Inside
- Metal Hardware For Wire Seal
- Adequate Space For Meter And Cut-Outs
- Wide Range For Different Applications
- Lightweight, Yet Strong
- Weatherproof
- Prices Matching Conventional Meter Boxes
- Shockproof
- Free From Pilferage
- Maintenance-Free
| Range & Specifications | ||
| Code No. | Inside Dimensions (mm) H x W x D | Description |
| Single Hinged Door | ||
| GSMB-2520 | 250 x 200 x 105 | L.T. 1 Phase KWh meter |
| GSMB-2522 | 250 x 220 x 135 | L.T. 1 Phase KWh meter |
| GSMB-2525 | 250 x 250 x 155 | L.T. 1 Phase KWh meter |
| GSMB-2835-PC | 285 x 230 x 150 | 10 meter box with transparent lid |
| GSMB-3428 | 340 x 285 x 120 | L.T. 3 Phase KWh meter |
| GSMB-3528 | 350 x 250 x 155 | L.T. 3 Phase KWh meter |
| GSMB-3527 | 350 x 270 x 200 | L.T. 3 Phase KWh meter |
| GSMB-2726 | 325 x 220 x 150 | L.T. 3 Phase KWh meter |
| GSMB-3920 | 390 x 200 x 105 | L.T. 3 Phase KWh meter |
| GSMB-3923 | 380 x 225 x 140 | L.T. 3 Phase KWh meter |
| GSMB-3727 | 370 x 270 x 210 | L.T.3 Phase Static KWh meter |
| GSMB-4030 | 400 x 300 x 190 | L.T. 3 Phase KWh meter |
| GSMB-4537 | 450 x 375 x 200 | L.T. 3 Phase KWh meter |
| GSMB-5345 | 530 x 450 x 175 | Multi-meter box for housing 4 nos. 1 Phase meters and 3 nos. 3 phase meters |
| GSMB-5030 | 500 x 300 x 230 | meter and modem box |
| GSMB-5431 | 540 x 310 x 200 | meter and modem box |
| GSMB-3757-I | 345 x 480 x 135 | 1 phase 2 meter box |
| GSMB-3750 | 345 x 480 x 210 | Multi-meter box for housing 3 nos. 1 Phase meters |
| GSMB-5728 | 570 x 280 x 220 | H. T. TVW with TTB |
| GSMB-6545 | 650 x 450 x 150 | Multi meter box housing 4 nos. 1-ph and 2 nos. 3-ph Kwh meters |
| GSMB-7450 | 700 x 480 x 210 | Multi meter box 6 nos. 1-ph and 4 nos. 3-ph KWh meters |
| GSMB-10069 | 1000 x 690 x 215 | Multi meter box housing10,12,16 nos. 1phase meters and 6,9 nos. 3 phase meters |
| Double Hinged Door | ||
| GSMB-4422 | 430 x 215 x 150/120 | L. T. phase KWh meter with MCB and with viewing window for MCB |
| GSMB-4422-I | 430 x 215 x 150/120 | L.T. 1 phase Kwh meter with MCB |
| GSMB-5628 | 505 x 240 x 150 | L.T. 3 phase KWh meter with MCB and with viewing MC |
| GSMB-5628-I | 505 x 240 x 150 | L.T. 3 phase KWh meter with MCB |
| GSMB-5628-II | 505 x 240 x 265/150 | L.T.3 phase KWh meter with MCB |
| GSMB-6535 | 650 x 350 x 250 | L.T.3 phase electronic KWh meter mounted on cast resin bar primary C. |
| GSMB-6535-I | 650 x 350 x 210 | L.T. TVM with CTs |
| GSMB-6535-II | 650 x 350 x 255 | L.T. TVM with CTs |
| GSMB-7627 | 760 x 270 x 170 | L.T. TVM with CTs |
| GSMB-8135 | 815 x 350 x 230 | L.T. TVM with CTs |
| GSMB-8535 | 850 x 350 x 250 | L.T. TVM with CTs |
| GSMB-9035 | 900 x 350 x 250 | L.T. TVM with CTs |
| GSMB-9045 | 900 x 450 x 250 | L.T. KWh/TVM with fuses / CTs / TTB |
| GSMB-7450 | 700 x 480 x 210 | Multi-meter box for housing4.6 nos.1 phase meters and 4 nos.3 phase meters |
| GSMB-10035 | 1000 x 350 x 230 | L.T. TVM with CTs and modem |
| Single Door Push Fit | ||
| GSMB-2550-T | 250 x 200 x 105 | 1 phase KWh meter (electronic) with P.C. transparent lid |
| GSMB-2619-T | 260 x 190 x 129 | 1 phase KWh meter (electronic) with P.C. transparent lid |
| GSMB-3428 | 340 x 285 x 120 | 1 phase Kwh meter (electronic) |
| GSMB-3833 | 384 x 334 x 125 | 3 phase electronic KWh meter |
| GSMB-3727 | 370 x 270 x 210 | 3 phase electronic KWh meter |
| GSMB-3727-I | 370 x 270 x 145 | 3 phase electronic KWh meter |
